How to use oven settings

Step
1

Fan oven

If your oven is one with a fan and its own heating element, it’ll have this icon or one that’s similar: most often it’s a fan inside a circle. This means that the element at the back of the oven will heat up and the fan will circulate the heat, spreading it evenly inside the cavity. Fanned heat ensures that you won’t get any cooler or hotter spots, meaning that whether you place a dish at the top or bottom, front or back, the results should be fairly consistent. Because of this, you can lower the oven temperature by 20C compared to the recommended top and bottom heat temperature.

This even heat is good for most types of cooking and means that you won’t have to keep moving trays around to get the best results for different dishes. Foods that need a good distribution of heat suit fanned cooking, such as roast meats and chunky vegetables, as well as those that benefit from its crisping effect – think pasta bake, pastry and lasagna. You should also be able to cook different types of dishes at the same time without being concerned about flavour transfer.

Fanned heat cooks faster than conventional heat – reducing cooking times and potentially your energy bills – but it’s not foolproof. Overfill your oven and air can struggle to circulate properly, leading to unevenly cooked food. The constant airflow of the fan can also dry some food out, so keep an eye on cakes and bread. If they look like they’re starting to dry, switch to the top and bottom heat, nudge the heat up, and pop them in the middle of the oven.

Step
2

Top and bottom heat (conventional)

With the option of fast, even fanned cooking on offer, you might wonder why ovens still come with top and bottom heat. The answer lies in the potentially drying effects of the fan. As mentioned above, cakes and bakes can suffer by losing moisture as they cook.

The conventional oven setting is shown by two lines that refer to where the elements are – one at the top, one at the bottom – and works without a fan circulating the heat. Instead, the heat spreads by natural convection, making it suitable for baked goods that are prone to drying out, such as biscuits, scones, pastries and fruit cake. It can also be used for roasting meat. As the heat isn’t fanned around the cavity, it’s best to stick to single-shelf cooking.

Step
3

Bottom heat only

Got a casserole or a stew? This is the setting to choose. It’s represented by a single line at the bottom of a box and refers to the oven using the bottom element only, without a fan. By using this element by itself, the oven fills with a gentle heat that’s great for slow cooking and mingling all of the flavours in your casserole. Bottom heat only lends itself well to crisping the base of a pizza or a pastry case or firming the bottom of a cake too. It can also double up for any function where you need gentle heat, such as reheating dishes.

Step
4

Grill / part grill

Sausages, steaks, bacon, and anything you might cook on a barbecue, suits the grill setting – represented by a zigzag line or triangles. You may have the option of only using part of the grill, in which case a full grill is usually shown as a double zigzag and the part grill as a single zigzag. The grill is also a good choice for browning the top of lasagna, making speedy kebabs, browning meat or toasting bread – though be aware that the latter can burn easily, so choose a low setting.

Step
5

Grill with bottom heat / Fan with bottom heat

Depending on your oven model, you may have the option of combining functions. Grill with bottom heat, for example, unites gentle heat from below with direct heat on top – making it good for tarts, pizza or pies where the aim is a crispy base and a browned top. Fan with bottom heat offers a similar benefit, which is ideal for crispy pizza bases, quiches and pies without the blind baking.

Step
6

Grill with fan

Adding the fan to the grill helps to spread out its fierce heat. This means it’s better at grilling large quantities of flat food, and provides a more even heat for toasting bread, so breakfast doesn’t get burnt as easily. It’s also handy for roasting without heating up the whole oven, meaning you can use it for cooking thicker pieces of fish or meat. The fanned heat shouldn’t burn the top or dry out the food like the grill might when used alone.

Step
7

Defrost

A no-heat setting that’s shown by a snowflake and droplet, the defrost setting uses the fan by itself. Rather than just leaving the food on the worktop, circulating air around it helps to reduce the defrosting time. It’s ideal for foods where the defrost setting on a microwave could start to cook, such as frozen cakes, fish and poultry, as well as when you’re in a rush to defrost dinner.
